LC-30
Forklift

LC-30

Rated Capacity:

3000kg

Power Type:

Diesel

Max. Lifting Height:

3000mm

TECHNICAL PARAMETER

3t Internal Combustion Counterbalanced Forklift Truck
Model LC-30
Power type Diesel
Rated capacity 3000kg
Driving mode Seat-type
Max. Lifting height 3000mm
Mast height, lowered 2070mm
Mast height, extended 4262mm
min. Ground clearance 135mm
Overall length (with fork / without fork) 3752mm / 2682mm
Service mass 4300kg
Tyre (front / rear) Pneumatic tyre
Tyre size (front / rear) 28×9-15-14PR /6.50-10-10PR
Internal combustion engine model QUANCHAI 4C2-50V32
Internal combustion enging rated output 36.8 / 2500
Emission China Stage
Engine Model and Main Specification for Option
Engine model (QUANCHAI) 4C2-50C41
Rated power/rotating speed (Kw/rpm) 36.8 / 2500
Rated power/rotating speed (Nm/rpm) 170 / 1500-1875
Engine displacement (L) 2.67
Engine cylinder number 4
Cylinder number – Bore × Stroke 4-90×105
Engine type Diesel
Emission China Stage/ Beijing Ⅳ
