LG388T
Backhoe Loader

LG388T

Rated power:

70kw/95HP

Bucket capacity:

1m³

Operating weight:

8200kg

TECHNICAL PARAMETER

Performance
Operating weight 8200kg
transport dimension(mm) 6150×2250×3763
Wheel base 2264mm
Min.Ground clearance 300mm
Bucket capacity 1.0m³
Breakout force 38KN
Rated loading 2500kg
Dumping height 2650mm
Dumping reach 1025mm
Loading cutting depth 52mm
Backhoe capacity 0.3m³
Max.Digging depth 4085mm
Digging slewing angle 190°
Max.Pulling force 39KN
Steering system
Diverter model BZZ5-250
Steering angle ±36°
Min.Turning radius 6581mm
System pressure 12MPa
Driving axle 4/18.5t
Engine
Model DEUTZ WP4G95E221
Type Inline, direct injection, water cooling, turbocharged, 4-strock
Cylinder-Inner diameter*stroke 4-105×130
Rated power 70kw/95HP
Rated speed 2200 r/min
Min.Fuel consumption 230g/kw.h
Max.Torque 380 N.m/1400~1600rpm
Displacement 4.5L
transmission/Gearbox
Model TLB1-4WD
Type Countershaft powershift/Electric contr
Hydraulic system
Bucket digging force 46.5KN
Total cycling time 11.9 ±0.15s
Tyre
Front/Rear model 14-17.5 / 19.5L-24
Air pressure of front tyre 0.55Mpa
Air pressure of rear tyre 0.23Mpa
travel speed 38km/h

Leave a Request

Our manager will contact you within 30 minutes of working hours





    SPECIAL FEATURES

    Manganese steel plate for vehicle structure

    The whole vehicle structure adopts manganese steel plate which brings high strength and good structural stability.

    Stable hydraulic system

    The improved and stable hydraulic system which ensures good working performance.
