LA60G
Skid Loader

LA60G

Bucket Capacity:

0.5m³

Rated Load:

850kg

Rated power:

45kw

TECHNICAL PARAMETER

Operating load (kg) 850
Max Speed(km/h) 12
Rated flux (L/min) 75
Tire(track) model 12-16.5
Rated power (Kw) 45
Fuel tank capacity (L) 60
self weight bucket (kg) 3200
Bucket capacity (m³) 0.5
Overall operating height (mm) 4000
Height to bucket hinge pin (mm) 3100
height to top of cab (mm) 2160
Height to bottom of level bucket(mm) 2933
Overall length ithout bucket(mm) 2750
overall length with bucket(mm) 3490
Dumping angle at maximum height(° ) 40
Dumping height(mm) 2400
Dumping reach(mm) 750
Rollback o bucket on ground(° ) 30
Rollback of bucket at full height(° ) 104
Wheelbase(mm) 991
Ground clearance(mm) 205
Angleof departure(° ) 20
Front turning radins without bucket(mm) 1198
Front tuning radius(mm) 1958
Rear tuning radius(mm) 1728
Rear axle to bumper (mm) 1208
tread width,enterline to centerline (mm) 1500
Width (mm) 1880
Bucket width (mm) 1880
